GP-S40 DMX RGB RGBW Facade LED Lighting Solution 40mm Led Pixel Dot

LED Pixel Dot Light Application

  • Bridge outlines, buildings, hotels, billboards, curtain walls, cultural and tourist attractions, night lights
  • Screen of extra exterior sign and building, Lighting for city signage.
  • Interior decorative lighting of Bar, KTV entertainment place and stage decoration.
Contact Supplier

Specification

40mm DMX RGBW facade lighting is a type of LED lighting system designed for illuminating building facades, bridges, and other architectural structures. The system consists of 40mm diameter LED fixtures that are capable of producing a wide range of colors using red, green, blue, and white LEDs.

    SKU     GPX-S40/RGB/RGBW
    Operating voltage      DC24V
    Power/Bulb     1.44W/1.92W
    SMD Type     SMD3535*6RGB /SMD3535*6RGB+2 White LED
    Lamp Qty/string     120 PCS/String
    Control Mode     2000-6500K, SPI, DMX512
    LED Chip     Epistar, Cree, Osram…..
    Luminous flux     42LM
    Material     PC
    Diameter    Φ39.8mm*14.4mm
    Beam angle     120°
    IP Rate     IP67
    Cable Type     2×0.75mm²+3×0.3mm²
    Operating Temp     -40℃ to 55℃

Product Feature

1. High thermal conductivity PCB and product is a beautiful and tidy structure
2. DMX512 control, With auto or manual address to meet the different occasions.
3. Also support SPI, like WS2811, UCS2903, and UCS1903 protocol.
4. Design with high-quality SMD 3535 lights in a variety of colors, such as red, green, blue, white, etc.
5. High-efficiency DC-to-DC power management design.
6. All potting glue craft, waterproof performance can achieve IP68, and can be totally used outdoors.
7. Control mode: DMX/SPI/2000K-6500K
8. OEM&ODM are available

Dimension Drawing

Installation

Application

DMX (Digital Multiplex) is a protocol that allows for the control of individual lighting fixtures, either individually or as a group, using a DMX controller. This enables the creation of dynamic lighting effects and color-changing sequences. By the way, consider the control options available for the system, including DMX controllers, smartphone apps, and remote controls. This allows for easy customization and control of the lighting effects.

Overall, 40mm DMX RGBW facade lighting is an excellent choice for illuminating building facades and other architectural structures. With their energy efficiency, long lifespan, and customizable design options, they can enhance the beauty and visibility of any structure at night while also providing a dynamic and engaging visual experience.
