Programmable DMX RGB LED Pixel Dots are a type of LED lighting system that consists of small, individually addressable LED modules that can be programmed to create dynamic lighting effects and animations. These lights are commonly used for decorative lighting, signage, and stage lighting.
With programmable dynamic pixel dot lights, users can create a wide range of lighting effects and animations using specialized software and controllers. This allows for the creation of dynamic and engaging lighting displays that can be customized to fit any space or occasion.
SKU | GPX-40/RGB/RGBW |
Operating voltage | DC24V |
Power/Bulb | 1.44W/1.92W |
SMD Type | SMD3535*6RGB /SMD3535*6RGB+2 White LED |
Lamp Qty/string | 120 PCS/String |
Control Mode | 2000-6500K, SPI, DMX512 |
LED Chip | Epistar, Cree, Osram….. |
Luminous flux | 42LM |
Material | PC |
Diameter | Φ41.6mm*11.4mm |
Beam angle | 120° |
IP Rate | IP67 |
Cable Type | 2×0.75mm²+3×0.3mm² |
Operating Temp | -40℃ to 55℃ |
1. High thermal conductivity PCB and product is a beautiful and tidy structure
2. DMX512 control, With auto or manual address to meet the different occasions.
3. Also support SPI, like WS2811, UCS2903, and UCS1903 protocol.
4. Design with high-quality SMD 3535 lights in a variety of colors, such as red, green, blue, white, etc.
5. High-efficiency DC-to-DC power management design.
6. All potting glue craft, waterproof performance can achieve IP67 and can be totally used outdoors.
7. Control mode: DMX/SPI/2000K-6500K
8. OEM&ODM are available
The Programmable DMX RGB LED Pixel Dots can be programmed in real-time, allowing for dynamic and changing displays. The key is that each pixel dot acts as an individually addressable and programmable light source that can be controlled and synced together to produce more complex visual effects. The finer the resolution of the DMX RGB pixel dots in a display (the more dots per inch), the higher the image quality and sharpness that can be achieved.
